RVLithTime 24V LiFePO4 Lithium Battery

RVLithTime specializes in high-performance 24V LiFePO₄ Lithium Batteries designed for RVs, solar energy storage, marine applications, off-grid systems, and backup power solutions.

RVLithTime 24V 100Ah LiFePO4 Lithium Battery For Marine, RV

~~$499.00 USD~~ $359.99 USD

Standard Lead-Acid Case & Lightweight Design, Easy Installation, Perfect To Replace Lead-Acid Battery

RVLithTime 24V 100AH LifePO4 lithium battery features a standard lead-acid battery case, Making it an ideal replacement for traditional 24V lead-acid batteries. The battery with an compact size of 19.69*9.61*7.32 inches, and lighter weighs 44 lbs.

EV Grade A LiFePO4 Cells

24V 100Ah Lithium Battery built with high-quality 3.2V premium EV Grade-A LiFePO4 cells. It achieves 4,000 cycles at 100% DOD and 6,000 cycles at 80% DOD, with a maximum cycle life of up to 15,000 cycles and a 10-year service lifespan. Designed for both indoor and outdoor applications, featuring compact and safe construction. It serves as an ideal direct replacement for two 12V 100Ah lead-acid batteries connected in series.

2S4P Configuration for 51.2V 400Ah | 20.48kWh Energy Storage

Expand voltage and capacity by connecting RVLithTime 24V 100Ah lithium batteries in series and parallel. Assemble 8 units of 24V 100Ah batteries in a 2S4P configuration to build a 51.2V 400Ah battery bank with a total energy of 20.48kWh. This robust energy storage solution is widely applicable to solar energy storage systems, emergency backup power supplies, and RV applications. The 24V 100Ah lithium iron phosphate batteries enable simplified wiring for easier power system setup.

Built-in 100A BMS & 2560W Max Output Power For Your Need

RVLithTime 24V 100AH lithium battery built-in 100A BMS, delivers 100A Max.continuous discharge current, Support 2560W Max Output Power. With overcharge, over-discharge, over-current, over-temperature, short circuits, Auto cell balancing Protection.

3 Ways to Charge

RVLithTime 24V 100Ah LiFePO4 batteries are compatible with LiFePO4 dedicated chargers, solar panels and generators. When charging with a 29.2V 20A LiFePO4 fast charger, the battery can be fully charged in approximately 5 hours, efficiently catering to your power needs.

IP65 Waterproof & Dustproof

The RVLithTime 24V 100Ah battery features a sealed ABS enclosure with an IP65 waterproof and dustproof rating, built to withstand harsh environments. It performs reliably against rain, snow, sand and dust, ensuring stable operation outdoors under tough conditions.

2560Wh Energy & Wide Use

The RVLithTime 24V 100Ah lithium battery delivers 2560Wh of usable energy, providing reliable, Perfect for Marine, Trolling Motors, RVs, Home Storage, Off-Grid applications. 24V 100Ah lithium ion battery simplifies setup with a one-step solution. Just Plug-and-Play.

FAQs

RVLithTime 24V LiFePO4 batteries feature an ultra-long cycle life, lighter weight, faster charging and higher efficiency than traditional lead-acid batteries. They require no regular maintenance and support deeper discharge and provide a consistent power output, It can reach over 4000 cycles at 80% DOD, Provide expected lifespan of 10 years, much longer than traditional lead-acid batteries. Perfect for solar storage, RV, marine and off-grid power applications.

Before storage, charge the RVLithTime 24V battery to 50%–60% SOC. Keep the battery in a dry, cool and well-ventilated environment with ambient temperature ranging from 10°C to 25°C; avoid direct sunlight, high humidity and freezing conditions. Disconnect all loads and chargers. Inspect and top up the charge every 3 months to prevent over-discharge caused by self-discharge.

Yes! RVLithTime support connect batteries in parallel and series. Batteries in parallel connection to increase the capacity, Batteries in series connection can raise the voltage. Please combined batteries with the same RVLithTime model, same capacity, Same BMS, same batch. Do not mix new and old batteries or units with different capacities.

RVLithTime 24V LiFePO4 battery support 3 charge method:

1、1. AC-DC Lithium Battery Charger: Select a dedicated 24V LiFePO4 charger with the appropriate voltage (29.2V±0.2V) to safely charge the battery. Lead-acid chargers are incompatible and must not be used.

2. Solar Panels: Connect a MPPT solar controller to ensure safe charging.

3. Alternator/Generator:DC Output: Need choose a DC-to-DC charger to connect the battery.AC Output: Need choose a compatible charger for safe charging.

No, Can't, it is not safe and not recommended.The nominal voltage of a 24V LiFePO4 battery pack is 25.6V, with a fully charged voltage up to 29.2V. This voltage far exceeds the rated working voltage of 12V equipment. Direct connection will overload and burn out 12V loads such as lights, pumps, inverters and controllers.

If your RV, boat, or off-grid system need to power 12V devices(such as 12V lights, pumps) from a 24V battery, you must install a high-quality 24V-to-12V DC-DC step-down converter. with sufficient rated current to match your load demand. Simple resistive voltage reduction is prohibited, which causes severe energy waste and overheating risks.

Yes. All of RVLithTime battery built-in a integrated BMS, the battery against overcharge, over-discharge, over-current, short circuit and overheating.

No. It is not recommended to fully discharge LiFePO4 batteries. The BMS will cut off discharge at around 20V to protect cells. Deep discharge will reduce battery service lifespan and performance. It's best to recharge the battery before it drops at 20% or higher.

RVLithTime 12V LiFePO4 lithium battery works for solar energy storage, RV, marine equipment, off-grid power systems and 24V DC electrical appliances.
