12V 100Ah LiFePO4 Battery

Group 24 Dimensions & Lightweight Design

RVLithTime 12V 100AH LifePO4 lithium battery was built based on the BCI Group 24 standard dimensions, Features a standard lead-acid battery housing, Making it an ideal replacement for traditional 12V lead-acid batteries with Group 24. The ultra-compact size of our battery is L10.2*W6.65*H8.39 in (Group 24 Size) / 259*169*213 mm, It enables simple drop-in Group 24 battery for RV power systems, marine and off-grid energy storage systems, And it also compatible with Group 27 or Group 31 applications. The Weigh of RVLithTime 12V 100AH LiFePO4 battery only 21 lbs, lighter than 12V lead-acid batteries, making it easier to installation, transportation, and remove.

EV Grade-A LiFePO4 Cells, 10+ Years Service Life

RVLithTime 12V 100AH lithium batteries made with 3.2V premium EV grade-A LifePO4 cells, Delivers 4000 cycles @100%DOD, 6000 cycles @80%DOD, It offers up to 15,000 cycles and a service life of 10 years. The energy of one RVLithTime 12V 100ah lithium battery is 1280Wh, Support 1280W max load power. It supports expandable to Max 4S4P, supports up to 20.48KWh energy and 20.48KW powerful power.

100A Smart BMS & Full-Protection

RVLithTime 12V/12.8V 100AH lithium battery Featuring a 100A BMS, With overcharge, over-discharge, over-current, over-temperature, short circuits, Auto cell balancing Protection. Intelligent low-temperature cut-off protection. delivers 100A Max.continuous discharge current and a 3% ultra-low self-discharging rate.

Multiple Charging Options

RVLithTime 12V 100AH Battery support three ways to charge, You can charge the battery via a compatible LifePO4 AC charger, solar panels paired with an MPPT charge controller, or a generator with a DC-to-DC charging system. Important: Always use charging equipment specified for LiFePO4 batteries to preserve battery performance and battery life.

One Battery, Powerful Performance For Wide Applications

RVLithTime 12V 100ah LiFePO4 battery is engineered for RVs, marine vessels, trolling motors, camping, off-grid cabins, home energy storage and more. Compatible with most 12V power systems, It stands ready to fulfill all your power demands across diverse scenarios.

Supports series-parallel connection, Max 4S4P, Expandable up to 20.48kWh

RVLithTime 12V 100Ah lithium battery supports series-parallel connection, Up to maximum configuration of 4S4P, Connect 16 units in series-parallel to build a 48V(51.2V) 400AH battery pack,  It delivers a substantial 20.48kWh energy reserve & maximum continuous discharge current of  400A & maximum load power of 20.48kW. Flexible series-parallel wiring lets you customize your energy system to power residential setups, marine vessels, camping, RVs, lawn equipment and off-grid installations, perfectly suited for applications demanding extended runtimes.

IP65 Waterproof for Harsh Environment Applications

RVLithTime 12V 100AH battery features an IP65 waterproof rating, Build with ABS housing, It delivers reliable protection against moisture, salt spray and dust, making it ideal for harsh working conditions.
